Features
• 1-1/2 in (38.1 mm) end-porting
• High flow – 100 gpm (378 lpm) in a compact, portable size
• Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
• Patented, high-reliability closed center air valve is online serviceable
• Lube-free operation
• Epoxy-coated air section
• External controller for optional remote operation
Typical Applications
• Tank transfer
• Tank stripping
• Chemical tank plating
• Transferring high temperature acids and gases
Typical Fluids Handled
• Chemicals
• Corrosive fluids
• Acids and gases: acetic, chromic, hydrochloric, hydrofluoric, sulfuric, nitric and phosphoric
Technical Curve
Dimensional
